| 型 號 | Model | YG-G1 |
| 電 源 | Power | AC220V 50/60 Hz 單相 AC220V 50/60 Hz single-phase |
| 功 能 | Function | 電線切斷、單端剝皮、雙端剝皮、單端壓著、單端扭線、單端半剝 Wire cutting, single-end stripping, both-end stripping, single-end pressing, single-end twisting, and single-end half-stripping |
| 產 能 | Productivity | 不扭線4800 條 / 小時、扭線3500條/小時（300mm以內） No twisting: 4800 pieces/hour; twisting: 3500 pieces/hour (within 300mm) |
| 電線規格 | Wire specification | AWG32 -- AWG18 |
| 剝皮長度 | Stripping length | 0.5mm-13mm |
| 加工長度 | Processing length | 19mm -- 9999mm（指中間留皮部分refer to the middle part with skin） |
| 切斷精度 | Cutting precision | 誤差少于1mm(設定長度x0.002)可修正 The error less than 1mm (set length x 0.002) can be corrected. |
| 扭線長度 | Twisting length | 3mm--20mm |
| 空氣壓力 | Air pressure | 5--8kgf(需使用清潔干燥空氣) 5-8kgf (need clean and dry air) |
| 檢測裝置 | Testing equipment | 入線異常、氣壓不足、沖模不良、端子有無、未打端、未剝皮 Abnormal entering, insufficient pressure, unsound punching, no terminal, no ending, and no stripping |
| 壓著能力 | Pressing capacity | 2.0 tons |
| 外觀尺寸 | External dimensions | 680W x 850L x 1250H mm |
| 重量 | Weight | 320kg |
